TP-LINK EAP110-Outdoor v3.0 300Mbps Wireless N Outdoor Access Point Εξωτερικού Χώρου

TP-LINK EAP110-Outdoor v3.0

Tο EAP110-Outdoor v3.0 High Power Wireless Access Point της TP-LINK είναι ιδανικό για ασύρματα δικτύα εξωτερικού χώρου.Διαθέτει δύο ενσωματωμένες 5dBi κεραίες Omni και είναι συμβατό με το δωρεάν λογισμικό Auranet Controller που σας επιτρέπει να διαχειρίζεστε εκατοντάδες EAPs.

• Built for outdoor Wi-Fi applications
• Up to 300Mbps Wi-Fi with 2x2 MIMO technology
• High transmission power and high gain antennas provide a long-range coverage area
• Durable, weatherproof enclosure to withstand fair and foul weather
• Passive PoE(Power over Ethernet) support and simple mounting design allow for flexible deployment and convenient installation
• Free Omada Controller software enables administrators easily manage hundreds of EAPs
• Captive portal provides a convenient method for guest authentication
• Facebook Wi-Fi and SMS anthentication help to boost your business
• Supports management vlan for an enhanced network management

.

Τεχνικά Χαρακτηριστικά:

HARDWARE FUTURES

• Interface: Fast Ethernet (RJ-45) Port *1（Support Passive PoE）
• Button Reset
• Power Supply: 24V Passive PoE (+4,5pins; -7,8pins. PoE Adapter Included)
• Power Consumption: 3.12 W
• Dimensions ( W x D x H ): 8.5 × 1.8 × 1.1 in. (216 × 46 × 27 mm)
• Antenna Type: 2*3dBi External Omni waterproof
• Mounting: Pole / Wall Mounting (Kits included)

WIRELESS FEATURES

• Wireless Standards: IEEE 802.11n/g/b
• Frequency: 2.4GHz
• Signal Rate: 11n: Up to 300Mbps(dynamic)
  11g: Up to 54Mbps(dynamic)
  11b: Up to 11Mbps(dynamic)
• Transmit Power: CE：
  ≤20dBm (EIRP)
  FCC:
  ≤22dBm
• Wireless Functions: Multiple SSIDs（Up to 8 SSIDs）
  Enable/Disable Wireless Radio
  Automatic Channel Assignment
  Transmit Power Control （Adjust Transmit Power on dBm）
  QoS(WMM)
  Load Balance
  Rate Limit
  Reboot Schedule
  Wireless Schedule
  Wireless Statistics based on SSID/AP/Client
• Wireless Security: Captive Portal Authentication
  Access Control
  Wireless Mac Address Filtering
  Wireless Isolation Between Clients
  SSID to VLAN Mapping
  Rogue AP Detection
  802.1X Support
  64/128/152-bit WEP / WPA / WPA2-Enterprise,
  WPA-PSK / WPA2-PSK

MANAGEMENT

• Auranet Controller Software: Yes
• Email Alerts: Yes
• LED ON/OFF Control: Yes
• Management MAC Access Control: Yes
• SNMP: Yes
• System Logging Local/Remote Syslog: Yes
• Telnet: Yes
• Web-based Management: HTTP/HTTPS
• L3 Management: Yes
• Multi-site Management: Yes
• Management VLAN: Yes

OTHER

• Certification: CE, FCC, RoHS
• Package Contents: 300Mbps Wireless N Outdoor Access Point, EAP110-Outdoor
  Passive PoE Adapter
  Power Cord
  Mounting Kits
  Waterproof Rubber Insert
  Waterproof Antennas
  Installation Guide
• System Requirements: Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10
• Environment: Operating Temperature: -30℃~65℃ (-22℉~149℉)
  Storage Temperature: -40℃~70℃ (-40℉~158℉)
  Operating Humidity: 10%~90% non-condensing
  Storage Humidity: 5%~90% non-condensing

Σχετικά Έγγραφα:

Installation guide
